Home  >  Concrete Machinery  >  Boom Pump  >  Jiuhe Boom Pump  >  Jiuhe JHZ5447THB-63
  • Overview
  • Specifications
Overview

Intelligence

Full hydraulic control technology

Fast fault location, saving time more than 50% in fault detection.

Electric control system

Intelligent electric control system, simple structure, reducing electric faults.


Safety

Hydraulic oil level Auto-detection and radiating technology

Auto-detect hydraulic oil and temperature, protecting hydraulic system.

Intelligent safety technology

All weld lines by 100% nondestructive flaw detection.


High efficiency

Full hydraulic commutation technology

Commutation time 10% lower, pumping efficiency 20% higher.

Advance Jib structure technology

Flexible and efficient placing, no blind angle.


Intelligence

Full hydraulic control technology

Fast fault location, saving time more than 50% in fault detection.

Electric control system

Intelligent electric control system, simple structure, reducing electric faults.


Safety

Hydraulic oil level Auto-detection and radiating technology

Auto-detect hydraulic oil and temperature, protecting hydraulic system.

Intelligent safety technology

All weld lines by 100% nondestructive flaw detection.


High efficiency

Full hydraulic commutation technology

Commutation time 10% lower, pumping efficiency 20% higher.

Advance Jib structure technology

Flexible and efficient placing, no blind angle.


Specifications

I.   Chassis
1Chassis BrandFoton/Faw/Isuzu
2Driving type8*4
3Power460HP
4Steering typeLeft hand drive
5Emission standardChina 5
II.   Boom system
1Max. Vertical   height(M)63
2Max. Horizontal   Concrete Placing radius (M)57.5
3Concrete placing   depth(M)45.1
4Boom structure63X-6RZ
5Rotating angle of   turret360°
6Length of end   hose (MM)3000
7Concrete delivery   pipe dia.  125
III.   Electric Control System
1Working voltage(V):       24
IV.   Hydraulic transmission system
1Type of hydraulic   systemOpen type
2System working   pressure (Mpa)31.5
3Displacement of   main hydraulic oil pump (ml/r)    260
4Hydraulic fuel   tank capacity (l)600
5Cooling mode of   hydraulic oilForced-air   Cooling
VII.   Pumping system
1Form of concrete   distribution valveS Valve
2Concrete cylinder260
3Maximum feeding   height (MM)        1550
4Hopper capacity   (M3 )0.65
5Slump of pumped   concrete160-220
6Dimension of   allowable maximum aggregate (MM)40
7Lubricating   methodCentralized   lubrication
