Sunhunk K2680
  • Sunhunk K2680
  • Sunhunk K2680
  • Sunhunk K2680
  • Sunhunk K2680
High Performance Crane

Sunhunk K2680

  • 61400kg
    Rated load
  • 248t.m
    Rated lifting capacity
  • 18.9m
    Max. working range
View Complete Details
  • Overview
  • Specifications
Overview

SUNHUNK's Most Capable All-folding Crane


♦ Multiple optional configurations (including winches and flying arms) are available to meet personalized customization needs.


♦ The structure is compact and uses high-strength steel, resulting in a lighter overall weight.


♦ Advanced hydraulic system improves the boom extension speed, achieving anti-vibration and multi-action linkage with proportional action functions.


♦ The entire vehicle is electronically controlled and equipped with standard wireless remote control operating system for convenient operation.


♦ Standard large-span double-stage hydraulic telescopic legs ensure operational stability.

Specifications
Rated load 61400kg
Rated lifting capacity 248t.m
Max. working range 18.9m
Maximum lifting height 22.5m
Number of boom sections 8sections
Maximum angle of elevation 75°
Swing angle 360°
Support leg spread 8170/7870mm
System displacement 115+50L/min
Crane self-weight 39500kg
System rated pressure 33mpa
