Sunhunk S1606
  • Sunhunk S1606
Stiff Boom Crane

Sunhunk S1606

  • 6400kg
    Rated load
  • 16t.m
    Rated lifting capacity
  • 18.8m
    Max. working range
View Complete Details
  • Overview
  • Specifications
Overview

SUNHUNK Straight Boom Cranes

1、The key structural components are welded with Q690 high-strength steel plate, which has high strength and light weight.


2、The boom is an enhanced hexagon structure with stable telescoping and a lifting capacity 20% stronger than conventional hexagon structures.


3、The boom telescoping mechanism is imported with a three-stage cylinder and rigging telescoping, sequential extension, and the first two telescoping arms are driven by independent cylinders. The medium and short arms have strong load-bearing telescoping capabilities.


4、The maximum operating range is 18.8 meters, which is the largest in the industry for the same tonnage and has strong cross-obstacle capabilities.

5、The standard configuration includes a torque limiter (which can be overridden) for higher safety.


6、The main moving parts and electrical and hydraulic components can work in low temperatures (-40°C), with stronger adaptability.


7、The standard configuration includes high-pressure filters to improve the cleanliness of hydraulic oil and extend its service life.


Specifications
Rated load 6400kg
Rated lifting capacity 16t.m
Max. working range 18.8m
Maximum lifting height 20.65m
Number of boom sections 5sections
Maximum angle of elevation 75°
Swing angle 360°
System displacement 63L/min
Crane self-weight 3300kg
System rated pressure 23mpa
