XCMG XDY2000
  • XCMG XDY2000
Core Drilling Rig

XCMG XDY2000

  • 2000 (BQ)m
    Drilling depth
  • 5600N·m
    Max. torque
  • 1250rpm
    Max. rotation speed
View Complete Details
  • Overview
  • Product Features
  • Specifications
Overview

XDY2000 core drilling rig is specially designed for the general investigation and exploration of minerals which need coring operation, and it is applied to a great variety of high efficiency drilling process such as diamond wire-line coring. The equipment is powered by hydraulic system, and has a lot of merits like easy operation and convenient transportation. It can be widely used in the exploring of mining, nonferrous metals, chemical industry and coal field.

Product Features
XCMG XDY2000
Specifications
Drilling depth 2000 (BQ)m
Max. torque 5600N·m
Max. rotation speed 1250rpm
Max. pull of main winch 150/80kN
Rated power 179kW
Engine QSB8.3
Emission standard CN III
Weight 13.8t
Transport dimensions 6900×2410×2730mm
