Efficiency
Featuring an internationally recognized engine and hydraulic components, this machine offers fast and efficient operations.
Reliability
The boom and bucket rod use a combination of forged welding, honeycomb bushings, and wear-resistant bucket features, enhancing overall reliability.
Safety & Comfortable
The F-series cab’s new structure includes optimized air conditioning channels and vents for reduced ventilation resistance, low noise, and quick temperature adjustment. Ergonomically designed seating enhances operator comfort.
| Operating Weight | 32950kg |
| Bucket Capacity | 1.7m³ |
| Rated Power | 225kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 11350X3200X3615mm |
| Max.Digging Radius | 10662mm |
| Max.Digging Height | 10269mm |
| Max.Digging Depth | 6727mm |
| Max.Unloading Height | 7169mm |
| Bucket Digging Force | 218kN |
| Stick Digging Force | 169kN |
| Track Width | 600mm |
