Intelligent
Newly developed Lovol's intelligent operation system enables intelligent interaction, automatic recognition of working conditions, auxiliary operation, and personalized customization.
Safe and comfortable
New structure F series cab, optimized air conditioning ducts and vents, low ventilation resistance and noise, fast temperature adjustment; Cab meets FOPs & ROPs regulations, making driving safer.
Efficient
Utilizing Weichai Linde hydraulic powertrain technology, optimized swing logic, providing multiple loading angles to adapt to different working conditions, achieving maximum work efficiency. Overall work efficiency improved by 10% compared to E series, fuel efficiency increased by over 15%.
Reliable
Global leading test benches for engine, main pump, and main valve components, multifunctional comprehensive testing ground for the whole machine, PXE material fuel tank larger and cleaner, large cross-section three-stage boom, forged axle seat, making the entire machine more reliable.
| Operating Weight | 21000kg |
| Bucket Capacity | 1m³ |
| Rated Power | 133kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 9580×2800×3200mm |
| Max.Digging Radius | 9875mm |
| Max.Digging Height | 10190mm |
| Max.Digging Depth | 6510mm |
| Max.Unloading Height | 7260mm |
| Bucket Digging Force | 156kN |
| Stick Digging Force | 109kN |
| Track Width | 600mm |
