Lovol FR20F-u
  • Lovol FR20F-u
  • Lovol FR20F-u
  • Lovol FR20F-u
  • Lovol FR20F-u
Mini Excavator

Lovol FR20F-u

  • 2000kg
    Operating Weight
  • 0.04m³
    Bucket Capacity
  • 10.9/2400kW
    Rated Power
View Complete Details
  • Overview
  • Specifications
Overview

Flexible

Tailless, side swing arm, telescopic chassis, split cab, foldable dozer blade, quick-coupling device for various attachments, switchable single/double-direction breaker lines, all highlighting the machine's flexibility.

Efficient

Large displacement main pump and travel motor, high-torque cycloidal swing motor, large bucket capacity, significantly enhancing work efficiency.

Reliable

Yanmar engine, imported hydraulic components; Boom and arm equipped with anti-burst valves; Internal hydraulic piping; Safety-certified cab; Cast steel structure for boom side shift and boom front fork rear seat, overall reliability and durability.

Comfortable

FOPs & ROPs cab, one-button start, new intelligent instrument panel, multi-directional adjustable seat for ergonomic functionality, cup holder, phone box, headrest, three-way opening covers. Both operation and maintenance are very convenient and comfortable.

Specifications
Operating Weight 2000kg
Bucket Capacity 0.04m³
Rated Power 10.9/2400kW
Emissions EU Stage V
Transportation Dimensions(L*W*H) 3575*1040*2347mm
Max.Digging Radius 3905mm
Max.Digging Height 3400mm
Max.Digging Depth 2440mm
Max.Unloading Height 2310mm
Bucket Digging Force 15.2kN
Stick Digging Force 8.5kN
Track Width 230mm
