Easy maintenance
Easy and convenient maintenance: Easy to maintain, routine checks can be easily done from the ground, safe and convenient.
Reliable
Yanmar engine, Hengli hydraulic system, new chassis structure, wear-resistant materials used in frequently worn parts of the bucket and blade, FOPs & ROPs cab, making the entire machine more reliable.
Comfortable
Air-conditioned cab, human-centered design, LED display screen, more comfortable operation.
Efficient
Engine perfectly matched with optimized hydraulic system, large bucket capacity; Adaptable to various attachments, more flexible and efficient.
| Operating Weight | 5730kg |
| Bucket Capacity | 0.23m³ |
| Rated Power | 36.2kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 6090X1950X2660mm |
| Max.Digging Radius | 6065mm |
| Max.Digging Height | 5405mm |
| Max.Digging Depth | 3660mm |
| Max.Unloading Height | 3770mm |
| Bucket Digging Force | 50kN |
| Stick Digging Force | 31kN |
| Track Width | 400mm |
