Strong momentum
Custom high-power engine, with power exceeding the industry standard by 23%, precisely matched with a custom hydraulic system, providing powerful performance for complex working conditions.
Integration of advanced systems
Equipped with internationally leading brand hydraulic systems and self-developed constant power algorithms, it achieves perfect compatibility between the engine and hydraulic system, with smooth and precise control, fluid movements, and efficient and reliable operation.
Stable and durable structure
Increase the chassis size, and self-developed X-shaped track frame to widen the wheelbase and track gauge, enhancing stability. Fully sealed positive pressure cabin enhanced protection. The bucket uses wear-resistant materials, the boom is reinforced, and the rear support is forged. Standard configuration with weather-resistant and wear-resistant bulldozer blades for auxiliary construction, ensuring driving safety.
Smart comfort experience
One-button starts with an intelligent digital display, integrating multifunctional information. Whole vehicle optimization for NVH, reducing noise and vibration, commercial vehicle-grade seat comfort, equipped with Bluetooth audio and automatic air conditioning.
Convenient maintenance and expansion
The hood opens at a wide angle, making maintenance and servicing convenient. Various attachments can be optionally installed to meet different working conditions and expand application areas.
| Operating weight | 6T |
| Bucket capacity | 0.22m³ |
| Engine model | Yanmar 4TNV94L ；Yanmar 4TNV98 |
| Rated power | 36.2/2100 ; 46.3/2200 kw/r/min |
| Hydraulic pump model | Inline HP5V76 |
| Maximum flow | 160L/min |
| Overall length | 5960mm |
| Overall width | 1960mm |
| Overall height （to top of boom） | 2100mm |
| Overall height （to top of cab） | 2580mm |
| Arm length | 1630mm |
| Boom length | 3000mm |
| Blade | 1980*350width*height,mm |
