Special Purpose Excavator

Maxpower ME150-9F

  • 17T
    Operating weight
  • 0.53m³
    Bucket capacity
  • Cummins QSF3.8
    Engine model
View Complete Details
  • Overview
  • Specifications
Overview

Redesigned to increase digging power compared to the previous model, the slewing drive has been redesigned to increase slewing torque and smoothness, resulting in increased productivity. Productivity has increased by 15%.

Heavy-duty bucket design with thickened ear plates and flanged front blade design for longer and more reliable bucket operating life. Bucket connecting rod pin is strengthened to provide more digging force. The bucket rod is reinforced with specially customized forged parts, increasing the size of the joint, which is reliable enough to cope with harsh operating conditions, and can better meet the demands of high production and provide excellent stability.

The whole vehicle commercial vehicle level NVH optimization, effectively reduce the internal and external noise, vibration and roughness, so that the operator work more smoothly and comfortably, the same level of commercial vehicle driver's seat design, backrest lumbar support thickening design, increase the lumbar high-density cushioning, sitting for a long time without deformation, Bluetooth, a variety of sound modes of the audio system, high-power automatic cooling and heating air conditioning, three-dimensional surround wind conducive to the operator's activities and rest. and rest.

Large hood opening angle, convenient maintenance, radiator, engine three filters, cabin internal parts maintenance full view, maintenance is convenient and quick.

A variety of buckets, crushing hammers, augers, mechanical quick-change, hydraulic quick-change, rubber track blocks, etc. can be optionally installed to broaden the field of application and meet the needs of different working conditions.

Specifications
Operating weight 17T
Bucket capacity 0.53m³
Engine model Cummins QSF3.8
Rated power 86/2200kw/r/min
Hydraulic pump model Inline HP3V75
Maximum flow 165*2L/min
Overall length 7740mm
Overall width 2800mm
Overall height (to top of boom) 2880mm
Overall height (to top of cab) 3135mm
Arm length 2500mm
Boom length 4600mm
Blade 2460*932width*height,mm
Max. Blade lifting height 382mm
Max. Blade digging depth 212mm
