Overview

Performance

Excellent work efficiency and outstanding price/performance ratio.

Simple operation, compact and flexible, convenient transportation, and adapted to narrow work conditions.

Equipped with dozer blade as standard, it can be used in the grading and backfilling work, and it also improves the overall stability.

It can replace attachments quickly, capable of excavation, crushing, trench clearing, drilling, bulldozing and other functions, which greatly improves the machine utilization rate.


Characteristics

Pilot operating System

Adjustable bulldozing plate

Optional breaker and piping

Smooth, quick and powerful digging operations

Outstanding durability



Specifications
ItemsParameters
Machine weight kg2050
Bucket capacity m³0.07(Standard bucket)

Rated engine power/revs  kW/rpm

20/2200

Hydraulic system pressureMpa

16

Overall length (transport status) mm

4150

Basic width(橡胶履带正装/反装) mm

1320/1380

Platform width mm

1160

Total height mm

2252

Ground clearance of platform mm

480

Height of engine hood mm

1280

Min. ground clearance mm

235

Tail swing radius mm

1255

Wheel tread mm

1261

Track length mm

1621

Standard track width mm

250

Travel speed km/h

2.7

Slewing speed rpm

13

Standard ground pressure kPa

32

Max traction kN

15

Gradeability

58%/30°

Bucket max digging force kN

14.8

Arm max digging force kN

8.8

Max digging radius mm

4250

Max digging depth mm

2270

Max digging height mm

3720

Max dump height mm

2480

Max digging reach on groundmm

4155

Digging radius at max height mm

2750

Max bulldozing depth mm

200

Max bulldozing height mm

335

Fuel tank volume L

23

Hydraulic tank volume L

40

Coolant volume L

1.9

Engine oil volume L

5

The structure and parameters are subject to change without prior notice due to technical progress. If the sample product is different from the actual product in some way, the actual product shall prevail.
