Efficient
High-pressure common rail electronically controlled injection engine, plunger hydraulic pump, fully hydraulic load-sensing steering system, pilot control with compound actions on the digging end, handle power cut-off function on the loading end, high efficiency and energy saving.
Reliable
Weichai engine, fully electronically controlled power shift transmission, wet rear axle with differential lock, 2/4-wheel drive switchable, plunger pump, box-type loading boom, reinforced frame and digging arm, waterproof connectors, reliable overall machine.
Comfortable
Spacious FOPS & ROPS cab, adjustable pilot control handle on the digging end, H-leg proximity switch limit, power cut-off function for parking brake, safer and more comfortable operation.
More Convenient
Quick change, telescopic boom, multiple attachment options, more convenient operation.
| Overall mass | 9800kg |
| Engine Rated Power | 74kw |
| Dimensions （L*W*H） | 6070X2420X3500mm |
| Engine brand | Weichai |
| Rated Power | 74kW |
| Max. Travel Speed | 32Km/h |
| Wheel Base | 2170mm |
| Tire（Front） | 12.5/80-18 |
| Tire（Rear） | 19.5L-24 |
| Bucket Capacity | 1m³ |
| Subtotal | 9.6s |
| Unloading Height | 2690mm |
| Unloading distance | 790mm |
| Digging Bucket Capacity | 0.18m³ |
| Bucket Digging Force | 45kN |
| Bucket rod digging force | 45kN |
| Max. Unloading Height | 3320/4030mm |
| Max. Digging Depth | 4490/5640mm |
| Max. Digging Radius | 5510/6610mm |
