Configuration selling point
The dedicated engine demonstrates robust power and exceptional energy efficiency. Shantui-specific high-strength chassis consisting of four wheels and one track ensures an extended service life. Integrated buttons for automatic lifting and bucket withdrawing allow for simple and precise operation.
Ease of maintenance and operation comfort
Centralized layout of filters facilitates easy maintenance. Spacious and well-sealed cab offers excellent visibility. Intelligent diagnostic system monitors various parameters in real time.
Adaptability to diverse working conditions
With integrated functions for pushing, loading, shoveling, and transportation, the machine is well-suited for complex working conditions such as urban underground spaces, wetland earthwork, mines, steel plants, ship cabins, forests, tunnels, and more.
| Engine power/speed | 231/2100kW/rpm |
| Operating mass | 29700kg |
| Bucket capacity | 3.2m³ |
| Machine external dimensions | 7345x2980x3510mm |
| Engine | Cummins QSL9 |
| Track center distance | 2160mm |
| Track shoe width | 660/830mm |
| Ground contact length | 2945mm |
| Ripper type | Three-tooth |
| Ripper penetration depth | 397mm |
| Emissions | T4FIndicated as per international standards |
