Overview

Equipped with Weichai WP10 National III electronic-control high pressure common rail engine, it features low speed torque, energy saving and environmental protection.

Highly efficient big capacity torque converter and highly reliable self-developed low revs transmission for outstanding comprehensive energy-saving effect.

Equipped with single pump high pressure working hydraulic system for low noise, high efficiency and energy saving.

Full hydraulic coaxial flow amplification steering system with no confluence enables light and flexible steering, and reliable work.

The hydraulic fuel tank uses high-precision paper filter element in the oil suction and oil return pipeline, which ensures the cleanliness of the hydraulic system.

It improves the reliability of the hydraulic system by using hydraulic accessories of high standards and new technologies in the industry.

The cooling system for the whole machine is optimized and the heat dissipation effect is good, ensuring the stability and reliability of the machine under harsh working conditions.

Single rocker arm Z-shaped tipping mechanism, optimized design of working device,  for big breakout force and lifting force.

The structural parts are subject to finite element analysis, and the key hinge joints adopt dustproof design, which ensures good lubrication of the pin shaft.

The working device can be automatically leveled, which contributes to reduced work cycle time and high efficiency.

Reinforced drive axle features high load bearing capacity and high reliability.

The service brake adopts air-over-hydraulic caliper disc brake, and the parking brake adopts flexible shaft controlled caliper brake.

Easy grease filling through using the lubrication hose at where it is difficult to access, which makes the service and maintenance more convenient.

Cab interiors use composite materials; capacious space and reasonably allocated operating devices enables convenient operation.

Intelligent instruments system offers real time monitoring of the overall working conditions.

Three power modes: “heavy load”, “medium load” and “light load” can be selected according to different working conditions to achieve fuel economy and consumption reduction.

Weichai Power WP10 National III electronic control low revs engine.

JinGong ZL50L low revs planetary power shift transmission.

Single-stage four-element double turbine hydraulic torque converter.

Reinforced drive axle independently made by JinGong.

Sunshade curtain, silk enclosure mat, heater, etc.

New aluminum water tank, with intercooler, torque converter oil cooler and hydraulic oil cooler.

New type waterproof connector harness, intelligent instruments, fuel sensor, GPS.

Specifications

Item

Parameters

Machine weight kg

16850

Rated load  kg

5000

Bucket capacity m3

2.7

Dump height mm

3150

Dump reach mm

1315

Max traction kN

163

Max breakout force  kN

168

Dimension (LxWxH) mm

7750×2990×3450

Boom lifting time s

5.5

Total cycling time s

10.5

Wheelbase mm

2920

Min. Turning radius(outer edge of bucket) mm

6670

Rated power kW

162

Travel speed

Forward gear I km/h

012

Forward gear II km/h

036

Reverse gear I/II km/h

017

Fuel tank volume L

290

Hydraulic tank volume  L

290


Parameters of variant working device

Item

Rock bucket

Common bucket

Coal bucket

High-dump

Unit

Standard bucket

Coal bucket

Bucket capacity

2.4

3.5

2.3

2.7

3.5

m3

Rated load

5000

5000

4300

5000

5000

kg

Machine weight

17030

17200

18300

17330

18000

kg

Dump height

3180

2990

2950

3510

3310

mm

Dump reach

1100

1215

1200

1170

1210

mm

Overall length

7790

7870

7970

8255

8440

mm

Min. Turning radius(outer edge of bucket)

6700

6820

6850

6870

7020

mm

The structure and parameters are subject to change without prior notice due to technical progress. If the sample product is different from the actual product in some way, the actual product shall prevail.
