Working Height | 26600mm |
Lift capacity | 256kg |
Weight | 18100kg |
Overall dimension-Stowed | 11760x2490x2950mm |
Overall dimension-Transportation | 9400x2490x3000mm |
Dimension of working platform | 2440x910x1150mm |
Wheelbase | 3000mm |
Fly jib length | 1850mm |
Ground clearance | 380mm |
Max.Platform height | 24.6m |
Max.Working range | 19.5m |
Max.up and over clearance | 8.7m |
Max.Occupants | 2 |
Max.Working slope | X-3°/ Y-3°° |
1st Boom luffing range | -1°~ +70°° |
2nd Boom luffing range | -35°~ +68°° |
Flying jib luffing range | -65°~ +70°° |
Turntable rotation | 360°° |
Platform rotation | 160°° |
Drive speed | 5stowed |
Drive speed | 0.6Up or extended |
Min.Turning radius | 2355/4625inside/outside |
Turntable tailswing | 2255stowed |
Max.Gradeability | 0.45% |
