| MODELS | M0607SE | M2030SE |
| Measurements | Metric | Imperial |
| Working Height Max | 8m/6.8m (in/out) | 26'3"/22'4" (in/out) |
| Platform Height (Raised) | 6m/4.8m (in/out) | 19'8"/15'9" (in/out) |
| Platform Size (L×W) | 0.7*0.75m | 28"*30" |
| A-Overall Length | 1.4m | 4'7" |
| B-Overall Width | 0.76m | 2'6" |
| C-Overall Height (Stowed) | 1.99m | 6'6" |
| Extension Deck | 0.5m | 1'8" |
| D-Wheelbase | 1.07m | 3'6" |
| E-Ground Clearance | 55mm | 2" |
| PRODUCTIVITY | ||
| Max. Platform Occupancy (in/out) | 1(in) / 1(out) | |
| Platform Capacity | 160kg | 352 lbs |
| Platform Capacity-Extension | 160kg | 352 lbs |
| Drive Mode | Front Wheels Drive | |
| Brakes | Front Wheels Brake | |
| Max. Drive Speed (Stowed) | 3km/h | 1.9mph |
| Max. Drive Speed (Raised) | 0.8km/h | 0.5mph |
| Gradeability | 25% | 25% |
| Tire Size | 305*100mm | 12"*4" |
| Ground Pressure, Tyres | 850 kPa | 123.3 psl |
| POWER | ||
| Power Source | 24V(2*12V), 100Ah, AGM | |
| HYDRAULIC SYSTEM | ||
| Hydraulic Oil Capacity | 5L | 1.3gal |
| WEIGHT | ||
| Machine Weight(ANSI) | 1170kg | 2579 lbs |
