Dingli BT2615ERTGS
  • Dingli BT2615ERTGS
Other Aerial Work Machinery

Dingli BT2615ERTGS

  • 10.29m/33ft 9in
    Overall Length(Stowed)
  • 10.43m/34ft 3in
    Overall Length(Transport)
  • 2.50m/8ft 2in
    Overall Width
View Complete Details
  • Overview
  • Specifications
Overview

● Pure electric drive, large suction 1500kg, no noise, zero emission, no pollution

● 8 independent suction cups, can rotate, tilt at any Angle, 3D movement (3D) unlimited operation

● High precision wireless remote control system, action accuracy up to millimeter level

● It can absorb more than ten kinds of common building decoration materials, including marble, glass, steel plate, wall panel, etc



Specifications
Overall Length(Stowed) 10.29m/33ft 9in
Overall Length(Transport) 10.43m/34ft 3in
Overall Width 2.50m/8ft 2in
Overall Width(Transport) 2.31m/7ft 7in
Overall Height 2.87m/9ft 5in
Overall Height(Transport) 2.54m/8ft 4in
Ground Clearance 0.41m/1ft 4in
Turntable Tailswing 1.61m/5ft 3in
Wheelbase 2.80m/9ft 2in
Tires 385/45-25
Max. Working Height(Glass Installed Horizontally) 21.93m/71ft 11in
Max. Working Height(Glass Installed Vertically) 19.62m/64ft 4in
Max. Horizontal Reach 10.85m/35ft 7in
Turning Radius(Inside/Outside) 1.87m/3.22m / 6ft 2in/10ft 7in
Turntable Rotation 360°Continuous
Grab Mechanism Shoulder Horizontal Swing Angle Range 15°
Grab Mechanism Up&Down Pitch Luffing Angle 172.5°(Coordinated By Main Boom Luffing)
Grab Mechanism Horizontal Telescopic Stroke 0.10m/4in
Grab Mechanism Elbow Pitch Angle Range -30~90°
Grab Mechanism Horizontal Swing Angle +/-60°
Grab Mechanism Up&Down Vertical Translation Stroke 0.20m/8in
Grab Mechanism Left&Right Lateral Translation Stroke 0.20m/8in
Grab Mechanism Wrist Rotation Angle 360°Continuous
Max. Working Slope
Wind Speed 12.50m/s
S.W.L 1500kg/3306lb
Overall Weight 19500kg/42990lb
Travel Speed(Stowed) ≯6.0km/h / ≯3.70mph
Travel Speed(Raised) ≯1.1km/h / ≯ 0.70mph
Gradeability 30%
Driving Motor XTQ18-1H/54VAC 18kW 3243RPM
Lifting Motor XYQD-24H/56VAC 24kW 2150RPM
Electronic Control System Voltage 12V
Hydraulic Tank 165L/43gal
Lithium Battery TFL-520-DL1/80V
Charger YP603-7280/90-264VAC
