Working Height | 18280mm |
Lift capacity | 300kg(unlimited)kg |
Weight | 8000kg |
Overall dimension-Stowed | 9000x2320x2520mm |
Overall dimension-Transportation | 7400x2320x2600mm |
Dimension of working platform | 1830x760x1150mm |
Wheelbase | 2360mm |
Fly jib length | 1420mm |
Ground clearance | 240mm |
Max.Platform height | 16.28m |
Max.Working range | 12.05m |
Max.Occupants | 2 |
Max.Working slope | X-5°/Y-5° |
Telescopic boom luffing range | -8°~+73.5° |
Flying jib luffing range | -60°~70° |
Turntable rotation | 360° |
Platform rotation | 160° |
Drive speed | 5.5km/hstowed |
Drive speed | 0.6km/hUp or extended |
Min.Turning radius | 3200mm/4700mminside/outside |
Turntable tailswing | 1400mmstowed |
Max.Gradeability | 45%(24°) |
