Working Height | 28200mm |
Lift capacity | 300kg(unlimited)/460kg(limited)kg |
Weight | 16500kg |
Overall dimension-Stowed | 12300x2490x3050mm |
Overall dimension-Transportation | 12300x2490x3050mm |
Dimension of working platform | 2440x910x1150mm |
Wheelbase | 3000mm |
Fly jib length | 1600mm |
Ground clearance | 310mm |
Max.Platform height | 26.2m |
Max.Working range | 20.6m |
Max.Occupants | 3 |
Max.Working slope | X-3°/ Y-3° |
Telescopic boom luffing range | -5°~ +73° |
Flying jib luffing range | -65°~ +70° |
Turntable rotation | 360° |
Platform rotation | 160° |
Drive speed | 6.1km/hstowed |
Drive speed | 1km/hUp or extended |
Min.Turning radius | 3600mm/6700mminside/outside |
Turntable tailswing | 1600mmstowed |
Max.Gradeability | 40% (22°) |
