Zoomlion ZT26JE
  • Zoomlion ZT26JE
Telescopic Boom Lift

Zoomlion ZT26JE

  • 28.70m|94ft 2in
    Work Height
  • 26.70m|87ft 7in
    Platform Height
  • 22.1m|82ft 6in
    Horizontal Outreach
View Complete Details
  • Overview
  • Specifications
Overview

Lithium-powered telescopic boom lifts, with 80-volt lithium battery that can be fully charged within 7 hours, are purpose-built for indoor applications with quiet, emission-free and cost-efficient solutions.

CE/ANSI/CSA Certified







Customized lithium-ion battery features green, environmental protection, lownoise and zero-emission, ideal for construction and plant maintenance.

lithium-ion batteries combined with excellent energy management systemprovide longer running time.

Low-temperature regenerative current control and power self-adaptive control effectively improve the safety of Li-ion battery and greatly prolong the batteries service life of at least 10%.

Provide a variety of standard charging plugs and 10A/16A/32A multi-power optional charging mode featuring strong charging Adaptability

Accurate and efficient traveling AC drive systemprovides strong power and stable control.

Gradeability reaches 45% and motor is maintenance-free for its lifttime.

Brand-new appearance with lightweight GFRP composite material hood and integrally formed coating features anti-corrosion, heat preservation, aging resistance and easy cleaning.

Assembled large-opening component box, open-close hood, and a variety of reserved inspection holeseasy to service.

Specifications
Work Height 28.70m|94ft 2in
Platform Height 26.70m|87ft 7in
Horizontal Outreach 22.1m|82ft 6in
A - Stowed Length 11.91m|39ft 1in
B - Stowed Width 2.49m|8ft 2in
C - Stowed Height 2.82m|9ft 3in
D - Platform Length 2.44m|8ft
E - Platform Width 0.91m|3ft
Jib Length 1.83m|6ft
F - Wheelbase 2.80m|9ft 2in
Tread 2.49m|6ft 12in
G - Ground Clearance 0.41m|1ft 4in
Platform Capacity (Unrestricted/Restricted) 300/454kg|660/1000lb
Drive Speed (Stowed) 5.5km/h|3.42mph
Gradeability 45% (24°)|45% (24°)
Turning Radius (Inside) 3.11m|10ft 2in
Turning Radius (Outside) 6.16m|20ft 3in
Turntable Swing 360°continuous|360°continuous
Platform Rotation ±90°|±90°
Tail Swing 1.61m|5ft 3in
Jib Rotation 130°(-55°~75)°|130°(-55°~75)°
Max. Wind Speed 12.5m/s|28mph
Battery 80V|80V
Charger 5KW/80V|5KW/80V
Drive Motor 5.2KW|5.2KW
Lifting Motor 30KW|30KW
Auxiliary Power 12V DC|12V DC
Hydraulic Tank 120L|32 US gal
Type 15-625 Foam-filled Tires385/65-24 Solid Tires|15-625 Foam-filled Tires385/65-24 Solid Tires
Gross 17600kg|39462lb
