Zoomlion ZT38JE
  • Zoomlion ZT38JE
Telescopic Boom Lift

Zoomlion ZT38JE

  • 40.22m|131ft 11in
    Work Height
  • 38.22m|125ft 5in
    Platform Height
  • 22.64m|74ft 3in
    Horizontal Outreach
View Complete Details
  • Overview
  • Specifications
Overview

Lithium-powered telescopic boom lifts, with 80-volt lithium battery that can be fully charged within 7 hours, are purpose-built for indoor applications with quiet, emission-free and cost-efficient solutions.

CE Certified







High-efficiency and energy-saving hydraulic system deadweight lowering technology, saving energy consumption by 23.6%; with load-sensing control technology, saving energy consumption by 13.8%

Safe and reliable lithium battery power system equipped with BMS low-temperature heating and low-temperature charging current control functions improves battery life by 30% and adapts to -20 ℃ cold environment

Maintenance-free wheel side AC drive system, the maximum gradeability can reach 45%

220V/380V full voltage adaptable charger - the three most common charging plugs 10A, 16A, 32A are matched with the matching signal plug on the charging head, can realize charging mode matching and adaptive power for charging

Specifications
Work Height 40.22m|131ft 11in
Platform Height 38.22m|125ft 5in
Horizontal Outreach 22.64m|74ft 3in
A - Stowed Length 12.26 (14.35) m|40ft 3in (47ft 1in)
B - Stowed Width 2.49/3.87m|8ft 2in (12ft 8in)
C - Stowed Height 3m|9ft 10in
D - Platform Length 2.44m|8ft
E - Platform Width 0.91m|3ft
F - Wheelbase 3.81m|12ft 6in
Tread 2.49/3.87m|8ft 2in (12ft 8in)
G - Ground Clearance 0.41m|1ft 4in
Platform Capacity (Unrestricted/Restricted) 300kg|660lb
Travel speed (stowed) 5km/h|3.1mph
Gradeability 45% |45% (24°)
Turning Radius (Inside) 3.3/7.7m|10ft 10in/25ft 3in
Turning Radius (Outside) 8.2/10.8m|26ft 11in/35ft 5in
Turntable Swing 360°|360°continuous
Platform Rotation ±90°|±90°
Tail Swing 1.46|4ft 10in
Jib Rotation -55°~75°|-55°~75°
Max. Wind Speed 12.5 m/s|28mph
Battery 606 Ah|606Ah
Charger 6kW|6kW
Drive Motor 30kW|30kW
Auxiliary Power 2kW,1.3CC|2kW,1.3CC
Hydraulic Tank 200L|52.8 (us gal)
Type IN445/50D710 Foam-filled|IN445/50D710 Foam-filled
Gross 19200kg|42328lb
