XCMG XUB125
  • XCMG XUB125
Rock Bolter

XCMG XUB125

  • Montabert HC25
    Drifter brand & model
  • 8kW
    Impact power
  • 1500 / 1800(Standard) / 2000mm
    Anchor bolt length
View Complete Details
  • Overview
  • Specifications
Overview

XUB125 is mainly suitable for the bolting operations in metal mines (such as underground gold mines, iron ores, and copper mines), non-metal mines (such as gypsum mines and phosphorite), hydropower projects, small tunnels, inclined shafts, culverts, etc;

The equipment adopts a hydrostatic transmission system, with a compact structure and flexible maneuverability;

The whole machine can be divided into several modules, which is convenient for access to the mine through cages;

The construction of the resin anchor bolt and the slit wedge tubing bolt can be completed mechanically in the whole process, and a mesh hanging gripper is optional.

Specifications
Drifter brand & model Montabert HC25
Impact power 8kW
Anchor bolt length 1500 / 1800(Standard) / 2000mm
Installed power 60kW
Power of engine 55.8kW
Emission standard CN IV
Cable length 80m
Total weight 11.5t
Dimension 9550×1600×2000mm
