Gross Vehicle Weight | 95000kg |
Max.Chassis Weight | 65000kg |
Emissions | Stage III |
Dimensions(L*W*H) | 9350×3610×4180mm |
Struck | 34m³ |
Wheel Base | 3885+1780mm |
Max.Travel Speed | 38km/h |
Max.Gradeability | 30° |
Min.Turning Diameter | 24m |
Min.Ground Clearance | 400mm |
Engine Model | WP12G460E310 |
Rated Power | 338kW |
Transmission | 8DS240A |
Axle Load Capacity | 25/35/35t |
Front Suspension Type | Longitudinal leaf spring |
Rear Suspension Type | Leaf spring balance suspension |
Frame Width | 1200mm |
Tyre Model | 16.00R25 ★★★ |
