Durable self-developed chassis system
The self-developed drive system has been widely proven in the market and has good durability. Provides high traction when combined with specialised engines
Ease Of Maintenance And Operation Comfort
The openable side guard offers a spacious area and the reasonable layout of filter elements and hydraulic components facilitate convenient maintenance. The hexahedral cab is designed with ergonomic considerations and provides a spacious interior and wide field of view.
Adaptability To Diverse Working Conditions
The machine is equipped with a straight tilt blade for enhanced cutting force. It offers the option of incorporating a three-tooth ripper to showcase its remarkable adaptability to diverse challenging conditions such as clay, hardened frozen soil, and more.
| Overall weight | 23450kg |
| Engine brand | Cummins NT855-C280S10/Weichai WP12G240E306 |
| Rated power/rated speed | 175/1800kW/rpm |
| Machine external dimensions | 6060*4200*3402mm |
| Track center distance | 2000mm |
| Track shoe width | 560/610/660mm |
| Ground contact length | 2430mm |
| Fuel tank capacity | 450L |
| Blade type | Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade |
| Blade capacity | 4.6m³ |
| Emissions | Eu stageⅡIndicated as per international standards |
