XCMG D360
  • XCMG D360
Dozer

XCMG D360

  • 39100Kg
    Operating weight
  • 3800mm
    Minimum turning radius
  • 97Kpa
    Ground pressure
View Complete Details
  • Overview
  • Specifications
Overview

The D360 Dozer utilizes hydraulic drive and electronically controlledgear shifting,providing optimum quality and top performance likeother XCMG machines.

It is primarily used for excavating,backfilling,pushing and transport-ing earth and rocks on highways,railroads,airports,rivers,and othersimilar jobs.This machine is indispensable for national defense proj-ects,urban construction,and water conservancy construction.This construction equipment utilizes cutting-edge technologies,including intelligent control,limit load,hydraulic blade control,elec-tronically controlled shift,and construction data management.Itoffers high efficiency,flexibility,and convenience,along with excep-tional reliability.

Specifications
Operating weight 39100Kg
Minimum turning radius 3800mm
Ground pressure 97Kpa
Overall dimensions 9090×4130×3700mm
Model NTA855Kw/rpm
Rated power/Rated speed 345/2000(kW/rpm
Forward gear 1 3.6km/h
Forward gear 2 6.8km/h
Forward gear 3 12.3km/h
Reverse gear 1 4.3km/h
Reverse gear 2 8km/h
Reverse gear 3 13km/h
Ground clearance 472mm
Track center distance 2140mm
Crawler width 560/610/660/710mm
Ground contact length of crawler 3150mm
Number of track shoes 41mm
Chain pitch 228.6mm
Number of track rollers 7one side
Number of carrier rollers 2one side
Fuel tank 680L
Hydraulic oil tank 139L
Blade type Half U blade
Blade width 4130mm
Blade height 1710mm
Blade capacity 9m³
Blade lifting height above the ground 1405mm
Blade depth 560mm
Ripper type single-tooth/three-tooth(option)
Working depth 1250/842mm
Ripper lifting height above the ground 1200/883mm
Max.traction force \KN
Forward \km/h
Reverse \km/h
Track gauge \mm
