XCMG RP705
  • XCMG RP705
Paver

XCMG RP705

  • 2500~5000mm
    Basic paving width
  • 6000~7500mm
    Max. paving width(Options)
  • 300mm
    Max. pave thickness
View Complete Details
  • Overview
  • Specifications
Overview

RP705 is a medium-sized full hydraulic tracked paver perfectly equipped with new intelligent control system and user-friendly HMI. The standard E500B four-support hydraulic screed has basic paving width ranging from 2.5m to 5.0m. This screed works with tampers and vibra- tors, hydraulic crown adjustment, hydraulic height adjustment (option). The machine is mainly used for paving asphalt concrete surface course of newly con- structed pavement, as well as road maintenance. The whole machine has compact structure, excellent visibility and high operating comfort, which is the ideal construc- tion equipment for municipal road construction and high-grade road maintenance.

Specifications
Basic paving width 2500~5000mm
Max. paving width(Options) 6000~7500mm
Max. pave thickness 300mm
Max. paving speed 24m/min
Max. drive speed 4km/h
Maximum theoretical productivity 600t/h
Max. gradeability 20%
Manufacturer Cummins
Model QSB4.5
Emission EC Stage Ⅲ
Fuel Diesel
Rated power 119kW
Rated speed 2200rpm
Grounding length 2700mm
Track width 300mm
Hopper capacity 13t
Scraper numbers 2
Scraper speed(maximum) 21m/min
Speed(maximum) 95rpm
Diameter 360mm
Battery voltage 24V
Tractor weight 14t
Operating weight 17.5t
Total weight 19t
Sound pressure level LPA at the operator ears 84dB(A
Emitted sound level 105dB(A
Main configuration 1. Cummins EC Stage Ⅲ engine with 119kW; 2. E500B four support hydraulic extending screed(electric heating, single tamper, eccentric vibration); 3. Upgraded intelligent control system; 4. MOBA leveling instrument/material level instrument; 5. Automatic centralized lubrication; 6. Electric arm extender pin; 7. Spraying device.
Options 1. E500 bolt-on extensions: 2×0.75m+2×0.5m, maximum paving width 7.5m; 2. E500 bolt-on extensions: 2×0.75m, maximum paving width 6.5m; 3. E500 bolt-on extensions: 2×0.5m, maximum paving width 6.0m; 4. Hydraulic quick-connect device; 5. Side skirt heating; 6. Side skirt overturning; 7. Hydraulic height adjustment.
